Korea CU AED Battery PQ030078 D 12V 4.0Ah Medical

1
MOQ
USD
Price
Korea CU AED Battery PQ030078 D 12V 4.0Ah Medical
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name:: Battery
Model:: PQ030078 D
Condition: NEW ORIGINAL
Type:: Medical Battery
Voltage:: 12V
Capacity:: 4.0Ah
Energy:: 48Wh
Weight:: 260g
Size:: 105mm×60mm×28mm
Warranty:: 90 Days
Highlight:

Korea CU AED battery 12V 4.0Ah

,

medical battery with warranty

,

AED replacement battery PQ030078
Basic Infomation
Place of Origin: Korea
Brand Name: CU MEDICAL
Model Number: 369108
Payment & Shipping Terms
Packaging Details: Carton Package
Payment Terms: T/T,Western Union,PayPal
Product Description
Korea CU AED Defibrillator Battery PQ030078 D 12V 4
The Korea CU AED Defibrillator Battery PQ030078 D is a non-rechargeable lithium-ion battery specifically designed for Korea CU AEDs. Utilizing a high-rate lithium-manganese battery cell, it delivers rapid energy release to provide ample current for AED operation. With stable power output and long-lasting storage, this battery serves as a reliable power source for emergency AED use.
Compatible Models
Designed for the Korean CU brand series of automated external defibrillators (AEDs), including:
  • CU I-PAD series (I-PAD SP1, I-PAD SP2)
  • CU Compact series
These AEDs are widely used in public emergency response, medical emergency rooms, and ambulances as critical equipment for sudden cardiac arrest situations.
Key Features
  • Automatic Rhythm Analysis: Provides stable power for interference-free ECG signal acquisition and accurate rhythm determination
  • Precision Defibrillation: Rapidly discharges energy to deliver preset defibrillation energy when needed
  • Voice Operation Guidance: Supports clear multilingual voice prompts to guide operators
  • Status Self-Check and Alarm: Periodic self-check function alerts users when battery replacement or maintenance is required
Technical Specifications
Product Name Battery
Model PQ030078 D
Brand Korea CU
Cell type Li-MnO₂
Voltage 12V
Capacity 4000mAh
Energy 48Wh
Discharge rate ≥5C (supports instantaneous high current output)
Interface Type CU AED dedicated metal contacts (2 pins)
Shelf life ≤5 years (unopened)
Size 105mm*60mm*28mm
Weight About 260g
Korea CU AED Battery PQ030078 D 12V 4.0Ah Medical 0 Korea CU AED Battery PQ030078 D 12V 4.0Ah Medical 1
Frequently Asked Questions
Q1: Is this battery rechargeable? Can it be recharged after use?
A1: No. PQ030078 D is a disposable lithium-manganese battery designed for single use and replacement when depleted. It is not rechargeable.
Q2: How can I tell if the battery is still within its expiration date? What precautions should be taken during storage?
A2: The "manufacture date" and "recommended expiration date" (usually 5 years after the manufacture date) are marked on the battery casing or packaging. Store away from high temperatures (>30°C), humidity (relative humidity >70%), and direct sunlight. It is recommended to store in a dry, cool indoor environment.
Q3: After installing a new battery, the AED device displays a "Battery Error" message. What should I do?
A3: First, check that the battery is correctly installed with clean connector contacts. If the error persists, try replacing with a new battery of the same model. If the message continues, the device's battery compartment or detection module may be faulty - contact after-sales service for repair.
